Processes

Stick (SMAW)

Flux-Cored (FCAW)

MIG (GMAW)

DC TIG (GTAW)

Non-Critical AC TIG (GTAW)

Air Carbon Arc (CAC-A) Cutting

and Gouging (3/16-in. carbons)

Air Plasma Cutting and Gouging

with optional Spectrum models

Industrial Applications

Maintenance

Repair

Farm/Ranch Applications

Fabrication

Structural Steel Work

Use as a Stand-Alone

Generator

Issued Feb. 2015 • Index No. ED/4.34

Output Range AC Stick/TIG 40 – 250 A

DC Stick/TIG* 40 – 275 A

FCAW/MIG 17 – 28 V

*DC TIG available above 80 amps.

Generator Power Output Rated at 104° F (40° C)

Peak: 11,000 W — Continuous: 9500 W

Welder/generator is warranted for 3 years, parts and labor.

Engine is warranted separately by the engine manufacturer.

Easy maintenance. With front

panel maintenance displays, you

know when your equipment needs

to be serviced.

Smooth power

—

not spike

power. Revolutionary ten-degree

skewed-rotor design optimizes

generator performance for

smoother power — not spiked

power found with other brands.

Better power — better performance.

Accu-Rated

™

—

not inflated

generator power. Our Accu-Rated

11,000 watts of

usable

peak

power is delivered for a minimum

of 30 seconds. See page 3 for

more information.

Versatile AC and DC weld output

provide quality welds on all types

of metals. DC is smooth and easy

to run while AC Stick is used when

arc blow occurs.

Front panel fuel and sight

gauges provide convenient fuel

level indication.

Note: Diesel engine will shut down

before system runs out of fuel making

restarts easy.

Smaller and lighter design.* Bobcat welder/generators take up less

space on trucks and trailers — leaving more room on your truck for

other equip ment and tools. Plus, they’re easier to move safely

around jobsites — even with weld cables and running gear attached.

*Compared to previous model.

Bobcat

™

250 Diesel

Diesel Engine-Driven

Welder/AC Generator

Quick

Specs

Miller Electric Mfg. Co.

An ITW Welding Company

1635 West Spencer Street

P.O. Box 1079

Appleton, WI 54912-1079 USA

MillerWelds.comEquipment Sales US and Canada

Phone: 866-931-9730

FAX: 800-637-2315

International Phone: 920-735-4554

International FAX: 920-735-4125

The most popular welder/generator

in the industry is getting better.

Building on its exceptional value,

the redesigned Bobcats are:

• Quieter to operate

• Smaller and lighter

• Easier to maintain

1 2 3 4 5 6 7 8

Summary of Contents

Page 1 - 250 Diesel

ProcessesStick (SMAW) Flux-Cored (FCAW) MIG (GMAW) DC TIG (GTAW)Non-Critical AC TIG (GTAW)Air Carbon Arc (CAC-A) Cutting and Gouging (3/16-in. carbons

Page 2 - Function and Benefit Guide

2Specifications (Subject to change without notice.)5671324Function and Benefit Guide1. Maintenance Displays provide fuel level, engine hours and oilch

Page 3 - Advantage

3For example, if you’re welding at 125 amps you also have 5200 watts available forpowering lights or tools (either 43 amps from the 120-volt full kVA

Page 4 - Accessories

4Genuine Miller®Options *Available as factory option. See ordering information on back page.Genuine Miller®Accessories GFCI Receptacles* #300 975 F

Page 5 - Accessories (Continued)

5MIG/Flux-Cored WeldingMillermatic 211 Auto-Set with MVP shown.Millermatic®141 #907 612See Lit. Index No. DC/12.42Millermatic®190 #907 613See Li

Page 6 - Mounting Specifications

64 HolesEngine EndGABCDEFMounting SpecificationsA. 20.5 in. (508 mm)B. 16.5 in. (419 mm)C. 2 in. (51 mm)D. 5.25 in. (133 mm)E. 32.75 in. (832 mm)F. 44

Page 7 - Typical Installations

7WorkStick ElectrodeWorkGunX-TREME 8VS/X-TREME 12VSFeederVolt-Sensing LeadWorkGunX-TREME 8VS/X-TREME 12VSFeederWorkGunVolt-Sensing LeadSpoolmate 3035/

Page 8 - Ordering Information

Equipment and Options Stock No. Description Qty. PriceBobcat™250 Diesel #907 565 Kubota engine, with GFCI ReceptaclesField Options Options listed b
